Ikelite #9312.26 O-Ring Set for Older Ikelite Housings 6" Diameter - New
$ 9.95
Ikelite #9312.26 O-Ring Set for Older Ikelite Housings 6" Diameter - New
Ikelite #9312.27 O-Ring Set for Older Ikelite Housings 7" Diameter - New
$ 9.95
Ikelite #9312.27 O-Ring Set for Older Ikelite Housings 7" Diameter - New
Ikelite #9312.28 O-Ring Set for Older Ikelite Housings 8" Diameter - New
$ 9.95
Ikelite #9312.28 O-Ring Set for Older Ikelite Housings 8" Diameter - New
Ikelite 200DLM/A Underwater Housing for Olympus PEN E-PL8 Mirrorless Micro Four-Thirds Digital Camera
$ 1,049.95
Ikelite 200DLM/A Underwater Housing for Olympus PEN E-PL8 Mirrorless Micro Four-Thirds Digital Camera
ikelite SKU: 6951.08 | Helix SKU: 695108
Overview
This housing requires the addition of a compatible lens port for waterproof operation. Lens port not included.
Superb handling
This powerful compact housing packs in all of our latest upgrades to controls and ergonomics. The shutter lever has been updated to a more sensitive and natural feeling curved design. The standard control hugs the side of the housing for comfortable use when hand holding. It can be easily extended using the optional Shutter Trigger Extension  # 4077.93 to put it within easy reach when using a right-hand quick release handle.
Controls are located in the same configuration as on the camera to replicate the muscle memory and familiarity you've developed with your camera on the surface.
Even our push buttons have been redesigned to reduce weight and salt build-up. The video record start/stop button is bright red anodized so that you never miss the action. The back of the housing features laser engraved control symbols which will never fade or fall off.
The camera mount is front-loading for easy installation and removal. A small mounting plate attaches to the bottom of the camera and secures in the front of the housing. The camera mounting plate does not need to be removed from the camera for surface use or when changing the battery or memory cards. The mounting plate features a 1/4-20 threaded mount on the bottom so that it can be attached to a tripod on the surface.
The camera's large, super-bright LCD screen is viewable edge-to-edge through the back of the housing.
True TTL exposure
Light is absorbed as it travels through even short distances underwater, making colors appear dull or monochromatic. To preserve the natural colors of your subject, it's important to stay within arm's reach—no more than 3-4 feet (1m) away.
An integrated TTL circuit is fine-tuned to the Olympus PEN E-PL8 flash exposure protocol for the most accurate exposure possible. The circuit is powered by the strobe for zero maintenance and no batteries to change. Exposure compensation in TTL mode is supported using the camera's built-in control. At this time, only Ikelite DS strobes are capable of powering the circuitry. SEA&SEA, INON, and Nikonos strobes will still enjoy fast recycle times and improved battery life, but must be used in manual exposure modes only.
This housing provides a direct electrical connection to the camera's external flash hot shoe. Cord attachment is as easy as screwing in a light bulb, and the threaded fit prevents accidental detachment during use. The bulkhead connection has been moved to the top of the housing to keep cords out of your way and reduce strain on the cord ends. A variety of sync cord terminations are available for Ikelite, SEA&SEA, INON, or Nikonos strobes for ultimate versatility.
The Olympus PEN E-PL8 camera does not feature a built-in flash. Triggering of fiber optic strobes is not supported at this time. A strobe must be connected by electrical sync cord.
A bright constant-on video light can be used instead of or in addition to a flash. A constant-on light is not as bright as a strobe flash. Constant-on lights do provide added versatility because they can be used for focus assist and for improved colors when shooting video.
Two 1/4-20 threaded mounting points are included on the bottom of the housing for the attachment of a tray and handle system. Handles provide improved ergonomics underwater and are the foundation for your lighting mounts.
There is a simple rule that brighter is better underwater. A high-quality lighting system can produce magazine quality results with almost any camera system.
The Lens Support You Want
It couldn't be more simple to change ports than this system—just press the port on and tighten three thumb screws. Feel positive reinforcement that the port is secure with simple parts you can trust in a remote location.
This housing accepts a variety of ports from our DLM Port System to accommodate all of the most popular zoom, macro, and wide angle lenses. Our custom optical grade acrylic domes components provide the color, clarity, and durability of glass at a fraction of the travel weight and cost.
Lens port sold separately.
Durability and corrosion free performance
Our new white ABS-PC blend housing provides strength and corrosion free performance year with minimal maintenance. The specially formulated color deflects the sun to keep your camera running cooler, longer. Compared to black or clear housings, the light color provides superior contrast for enhanced view of the camera, LCD screen, and o-ring seal.
The unique rear seal design prevents accidental twisting or stretching of the o-ring for simple and confident assembly. We have eliminated the need for an o-ring groove or channel which can trap sand, dirt, or debris. Two double-passivated stainless steel locking lid snaps are simple to use and virtually unbreakable. The clear back allows you to see the o-ring form a solid, watertight seal as it closes.
A spare 1/2-20 threaded accessory port is provided on the side of the housing for easily installation of the optional Vacuum Kit  # 47012. A vacuum kit allows you to pressurize the housing to check for proper assembly prior to entering the water.
Ikelite products are designed, built and tested in the USA. We use locally sourced, top-grade materials. Our housings are built by hand and individually tested for fit and function. Every unit is water pressure tested to 200 feet (60m). We back our products with over 50 years of experience and the best reputation for service within the dive industry.
This housing is only compatible with the PEN E-PL8 camera.
Strobe CompatibilityÂ
Serial number requirements
- AF35: not compatible
- DS50: yes, above serial number 70000
- DS51: yes
- DS125: yes, above serial number 5000
- DS160, DS161: yes
- DS200: yes, above serial number 7163
Electrical sync cord compatibility
- Ikelite-to-Ikelite TTL Sync Cord (TTL) Product 4103.51
- Ikelite-to-Ikelite TTL Dual Sync Cord (TTL) Product 4103.52
- SEA&SEA / INON Strobe-to-Ikelite Non-TTL Sync Cord (Manual) Product 4118.1
- SEA&SEA / INON Strobe-to-Ikelite Non-TTL Dual Sync Cord (Manual) Product 4118.2
- Nikonos SB Strobe-to-Ikelite Non-TTL Sync Cord (Manual) Product 4116.31
- Nikonos SB Strobe-to-Ikelite Non-TTL Sync Cord (Manual) Product 4116.32
Specifications
- 200 ft (60m) depth rating
- DLM Type A port mount
- Controls for all important camera functions; controls are not provided for Fn button or Zoom button
- Ikelite flash bulkhead connector with built-in TTL circuitry
- Two 1/4-20 threaded tray mounts with 3-inch (76mm) spacing
- Slightly negative buoyancy in fresh water
- Actual buoyancy varies depending on choice of lens and port
- 2.9 pounds (1.3 kg)
- 7.5 x 5.9 x 5.2 in (191 x 150 x 132 mm)
- ABS-PC, acrylic, and acetyl construction
What's Included
- Housing
- Housing Rear O-Ring # 0110
- Housing Front O-Ring # 0132.36
- Waterproof bulkhead cap # 9104.5
- Control + Push Button Tip Assortment # 9249.3
- 1/8" Hex Key # 0945.18
- Lubricant # 0184.1
- 1 year manufacturer warranty
Lens port required for waterproof operation. Lens port sold separately.
Ikelite Action Tray II Extension for Compact Housings
$ 20.00
Ikelite Action Tray II Extension for Compact Housings
Ikelite SKU: 2605.12 | Helix SKU: 2605.12
Overview
Extend the Action Tray II to make a dual tray. The Action Tray II is required to mount to a housing.
Specifications
- Hard anodized aluminum tray
- 5.6 oz (158g)
What's Included
- Extension
- Mounting hardware
Ikelite Action Tray II Extension with DS51 Strobe Arm for ULTRAcompact Housings
$ 55.00
Ikelite Action Tray II Extension with DS51 Strobe Arm for ULTRAcompact Housings
Ikelite SKU: 2605.09 | Helix SKU: 260509
Overview
Add a second strobe to an Action Tray II. The Action Tray II is required to mount to a housing.
Specifications
- Hard anodized aluminum tray
-
6.7 oz (189g)
What's Included
- Action Tray II Extension # 2605.12
- Flex Strobe Arm for Action Tray # 4087.27
Ikelite Action Tray II Extension with Light Arm for ULTRAcompact Housings
$ 55.00
Ikelite Action Tray II Extension with Light Arm for ULTRAcompact Housings
Ikelite SKU: 2605.07 | Helix SKU: 260507
Overview
Add a light any Action Tray II. The Action Tray II is required to mount to a housing.
Specifications
- Hard anodized aluminum tray
- 5.6 oz (158g)
What's Included
- Action Tray II Extension # 2605.12
- Flex Light Arm for Action Tray # 4087.26
Ikelite Action Tray II Extension with Right Handle for Compact Housings
$ 55.00
Ikelite Action Tray II Extension with Right Handle for Compact Housings
Ikelite SKU: 2605.05 | Helix SKU: 260505
Overview
Extend the Action Tray II into a dual handle assembly. The Action Tray II is required to mount to a housing.
Specifications
- Hard anodized aluminum tray
- Aluminum, ABS and rubber handle
- 7.1 oz (200g)
What's Included
- Action Tray II Extension # 2605.12
- Left-Handle Quick Release Handle # 9531.4
Ikelite Action Tray II for Compact Housings
$ 25.00
Ikelite Action Tray II for Compact Housings
Ikelite SKU: 2605.11 | Helix SKU: 260511
Overview
This super slim and streamlined tray is designed specifically for Ikelite Action and ULTRAcompact digital housings. Compared to our standard Tray with Quick Release Handle, the Action tray is lighter and brings the grip closer to the side of the housing for a more comfortable system.
Included is the necessary hardware to mount to Ikelite housings featuring female mounting points with 3" (76mm) spacing, as well as Action housings with central 1/4-20 mounting. The tray is machined specially to prevent rotation when attached to an Action housing.
Specifications
- Hard anodized aluminum tray
- 8.2 oz (233g)
What's Included
- Action Tray II
- Hardware Set for 1/4-20 Thread Housings # 9523.24
- Hardware Set for 12-24 Thread Housings # 9523.25
Ikelite Action Tray II with DS51 Strobe Arm for ULTRAcompact Housings
$ 65.00
Ikelite Action Tray II with DS51 Strobe Arm for ULTRAcompact Housings
Ikelite SKU: 2605.08 | Helix SKU: 260508
Overview
This super slim and streamlined tray is designed specifically for Ikelite Action and ULTRAcompact digital housings. Compared to our standard Tray with Quick Release Handle, the Action tray is lighter and brings the grip closer to the side of the housing for a more comfortable system.
The flex arm accepts any light mount which is compatible with 1/2" Loc-line flex components, including the 1/2" flex mounts offered by Light & Motion. Mounting of strobes or larger video lights is not recommended. To mount a strobe, use product # 2605.08 instead.
Add the Action Tray II Extension with Light Arm # 2605.07 for a dual handle tray.
Included is the necessary hardware to mount to Ikelite housings featuring female mounting points with 3" (76mm) spacing, as well as Action housings with central 1/4-20 mounting. The tray is machined specially to prevent rotation when attached to an Action housing.
This tray is not suitable for use with our housings for Mirrorless cameras or larger digital housings with stainless steel lidsnaps. Refer to the housing webpage for the correct tray recommendation.
Specifications
- Hard anodized aluminum tray
- 9.3 oz (263g)
What's Included
- Action Tray II # 2605.11
- Flex Strobe Arm for Action Tray # 4087.27
- Hardware Set for 1/4-20 Thread Housings # 9523.24
- Hardware Set for 12-24 Thread Housings # 9523.25
Ikelite Action Tray II with Left Handle for Compact Housings
$ 65.00
Ikelite Action Tray II with Left Handle for Compact Housings
Ikelite SKU: 2605.04 | Helix SKU: 260504
Overview
This super slim and streamlined tray is designed specifically for Ikelite Action, ULTRAcompact, and smaller compact digital housings. Compared to our standard Tray with Quick Release Handle, the Action tray is lighter and brings the handle closer to the side of the housing for a more comfortable grip.
The Ikelite Quick Release handle has become a favorite over the years for attachment and release of your lighting arm at the touch of a button. Accept no substitute. Add the Action Tray II Extension with Right Handle # 2605.05 for a dual handle tray.
Included is the necessary hardware to mount to Ikelite housings featuring female mounting points with 3" (76mm) spacing, as well as Action housings with central 1/4-20 mounting. The tray is machined specially to prevent rotation when attached to an Action housing.
This tray is not suitable for use with our housings for Mirrorless cameras or larger digital housings. Refer to the housing webpage for the correct tray recommendation.
Specifications
- Hard anodized aluminum tray
- Aluminum, ABS and rubber handle
- 10.6 oz (299g)
What's Included
- Action Tray II # 2605.11
- Left-Handle Quick Release Handle # 9531.3
- Hardware Set for 1/4-20 Thread Housings # 9523.24
- Hardware Set for 12-24 Thread Housings # 9523.25
Â
Ikelite Action Tray II with Light Arm for ULTRAcompact Housings
$ 65.00
Ikelite Action Tray II with Light Arm for ULTRAcompact Housings
Ikelite SKU: 2605.06 | Helix SKU: 260506
Overview
This super slim and streamlined tray is designed specifically for Ikelite Action and ULTRAcompact digital housings. Compared to our standard Tray with Quick Release Handle, the Action tray is lighter and brings the grip closer to the side of the housing for a more comfortable system.
The flex arm accepts any light mount which is compatible with 1/2" Loc-line flex components, including the 1/2" flex mounts offered by Light & Motion. Mounting of strobes or larger video lights is not recommended. To mount a strobe, use product # 2605.08 instead.
Add the Action Tray II Extension with Light Arm # 2605.07 for a dual handle tray.
Included is the necessary hardware to mount to Ikelite housings featuring female mounting points with 3" (76mm) spacing, as well as Action housings with central 1/4-20 mounting. The tray is machined specially to prevent rotation when attached to an Action housing.
This tray is not suitable for use with our housings for Mirrorless cameras or larger digital housings with stainless steel lidsnaps. Refer to the housing webpage for the correct tray recommendation.
Specifications
- Hard anodized aluminum tray
- 8.2 oz (233g)
What's Included
- Action Tray II # 2605.11
- Flex Light Arm for Action Tray # 4087.26
- Hardware Set for 1/4-20 Thread Housings # 9523.24
- Hardware Set for 12-24 Thread Housings # 9523.25
Ikelite AF35 Optical TTL Strobe
$ 429.95 - Sold Out
Ikelite AF35 Optical TTL Strobe - 4035
The AF35's built-in sensor transmits data from the camera's flash to the AF35 strobe, varying the strobe's power automatically to replicate TTL exposure. The AF35 sensor is positioned to provide the most reliable strobe triggering possible without exposed cables which require maintenance and can tangle or break.
Ikelite Aluminum Top Handle for DSLR, Mirrorless, and Compact Digital Housings
$ 189.95
Ikelite Aluminum Top Handle for DSLR, Mirrorless, and Compact Digital Housings
Ikelite SKU: 4080.08 | Helix SKU: 408008
Overview
Span your dual tray and arm system with this versatile top handle. The unique slotted ball arm doubles as both a handle and a mounting location for additional lighting, or a 67mm threaded lens holder. Works with dual trays for Compact Digital or DSLR housings with two lighting arms attached.
Attachment of this top handle requires that you have two strobe arms each having Clamps with Auxiliary Mount # 4081.22 at the base of each arm. This clamp comes standard with newer strobe arms # 4080.05 and # 4080.06.
Specifications
(2) Auxiliary Ball Mount # 4081.71
(2) Ball Clamp for Lightweight Accessories # 4081.21
7" Ball Arm # 4081.07
Ikelite Anti-Reflection Ring for Canon 10-18mm STM Lens
$ 10.00
Ikelite Anti-Reflection Ring for Canon 10-18mm STM Lens
Ikelite SKU: 0923.07 | Helix SKU: 092307
Overview
A self-adhesive vinyl label covers the white lettering and ring details on the front of the lens to reduce reflections when used behind a dome port underwater.
Designed specifically for use with the following lenses:
- EF-S 10-18mm f/4.5–5.6 IS STM
Ikelite Anti-Reflection Ring for Canon 16-35mm f/2.8 II USM Lens
$ 10.00
Ikelite Anti-Reflection Ring for Canon 16-35mm f/2.8 II USM Lens
Ikelite SKU: 092304 | Helix SKU: 092304
Overview
A self-adhesive vinyl label covers the white lettering and ring details on the front of the lens to reduce reflections when used behind a dome port underwater.
Designed specifically for use with the Canon 16-35mm f/2.8 II USM lens.
Ikelite Anti-Reflection Ring for Canon 16-35mm f/2.8 III USM Lens
$ 10.00
Ikelite Anti-Reflection Ring for Canon 16-35mm f/2.8 III USM Lens
Ikelite SKU: 0923.05 | Helix SKU: 092305
Overview
A self-adhesive vinyl label covers the white lettering and ring details on the front of the lens to reduce reflections when used behind a dome port underwater.
Designed specifically for use with the Canon 16-35mm f/2.8 III USM lens.
Ikelite Anti-Reflection Ring for Canon 16-35mm f/4 Lens
$ 10.00
Ikelite Anti-Reflection Ring for Canon 16-35mm f/4 Lens
Ikelite SKU: 0923.01 | Helix SKU: 092301
Overview
A self-adhesive vinyl label covers the white lettering and ring details on the front of the lens to reduce reflections when used behind a dome port underwater.
Designed specifically for use with the Canon EF 16-35mm f/4L IS USM lens.
Ikelite Anti-Reflection Ring for Canon 17-40mm f/4 USM Lens
$ 10.00
Ikelite Anti-Reflection Ring for Canon 17-40mm f/4 USM Lens
Ikelite SKU: 0923.02 | Helix SKU: 092302
Overview
A self-adhesive vinyl label covers the white lettering and ring details on the front of the lens to reduce reflections when used behind a dome port underwater.
Designed specifically for use with the Canon 17-40mm f/4 USM Lens.
Ikelite Anti-Reflection Ring for Canon 24-105mm Lenses
$ 10.00
Ikelite Anti-Reflection Ring for Canon 24-105mm Lenses
Ikelite SKU: 0923.06 | Helix SKU: 092306
Overview
A self-adhesive vinyl label covers the white lettering and ring details on the front of the lens to reduce reflections when used behind a dome port underwater.
Designed specifically for use with the following lenses:
- Canon EF 24-105mm f/4L IS USM
- Canon EF 24-105mm F3.5-5.6 IS STM
- Canon EF 24-105mm F4L IS II USM
Ikelite Diffuser M27 for Gamma
$ 14.95
Ikelite Diffuser M27 for Gamma
Ikelite SKU: 1870 | Helix SKU: 1870
Overview
Threads onto the front of the Gamma and other lights with M27 thread to spread out beam for use as a video or focus assist light. A special material provides exceptional light transmission and an extremely smooth pattern. Includes diffuser and lanyard.
Ikelite DLM 6 inch Dome Port with Zoom Extended .375 Inch
$ 424.95
Ikelite DLM 6 inch Dome Port with Zoom Extended .375 Inch
Ikelite SKU:Â 5516.16 | Helix SKU: 551616
Overview
An extended dome port providing zoom function for most mirrorless interchangeable zoom lenses when used with the appropriate zoom sleeve.
An optical-grade acrylic 6-inch diameter dome allows you to fully take advantage of the angle of view of your lens. Acrylic produces virtually identical image quality to glass yet is much lighter weight and easier to pack.
Our unique zoom sleeves are simple and affordable. Zoom sleeves are particular to the lens for proper operation. Refer to the appropriate port for your housing to determine compatibility.
A dome shade is in process for this item. It is expected to become available in late 2017.
Specifications
- Delrin body with acrylic dome
What's Included
- Dome Port
- Neoprene cover # 0200.1
- Silicone lubricant # 0184.2
Ikelite DLM 6 inch Dome Port with Zoom Extended 1.0 Inch
$ 449.95
Ikelite DLM 6 inch Dome Port with Zoom Extended 1.0 Inch
Ikelite SKU: 5516.17 | Helix SKU: 551617
Overview
An extended dome port providing zoom function for most mirrorless interchangeable zoom lenses when used with the appropriate zoom sleeve.
An optical-grade acrylic 6-inch diameter dome allows you to fully take advantage of the angle of view of your lens. Acrylic produces virtually identical image quality to glass yet is much lighter weight and easier to pack.
Our unique zoom sleeves are simple and affordable. Zoom sleeves are particular to the lens for proper operation. Refer to the appropriate port for your housing to determine compatibility.
A dome shade is in process for this item. It is expected to become available in late 2017.
Specifications
- Delrin body with acrylic dome
What's Included
- Dome Port
- Neoprene cover # 0200.1
- Silicone lubricant # 0184.2
Ikelite Flex Light Arm For Action Tray
$ 39.95
Ikelite Flex Light Arm For Action Tray
Ikelite SKU: 4087.26 | Helix SKU: 408726
Overview
A lightweight and flexible arm for the Action Tray II for compact digital housings. The 8.5" (216mm) long flex arm accepts any light mount which is compatible with 1/2" Loc-line flex components, including the 1/2" flex mounts offered by Light & Motion. Mounting of strobes or larger video lights is not recommended. To mount a strobe, use the Flex DS51 Strobe Arm for Action Tray product # 4087.27 instead.
This arm can be attached to the top of a Quick Release Handle using the # 9573.31 mount.
Ikelite Flex Mount for Gamma
$ 19.95
Ikelite Flex Mount for Gamma
Ikelite SKU: 1882 | Helix SKU: 1882
Overview
Based on our popular flex arm system, this mount kit includes everything you need to attach your Gamma to a 1/2 in or 3/4 in flex arm. Gamma flashlight not included.
Ikelite Flex Strobe Arm For Action Tray
$ 39.95 - Sold Out
Ikelite Flex Strobe Arm For Action Tray
Ikelite SKU: 4087.27 | Helix SKU: 408767
Ikelite Flex Strobe Arm For Action Tray
$ 39.95
Ikelite Flex Strobe Arm For Action Tray
Ikelite SKU: 4087.27 | Helix SKU: 408727
Overview
A lightweight and flexible arm for the Action Tray for compact digital housings. The 10" (254mm) long flex arm accepts a DS50 or DS51 strobe. Mounting of larger strobes is not supported. To mount a video light, use product # 4087.26 instead.
This arm can be attached to the top of a Quick Release Handle using the # 9573.31 mount.
Ikelite Focus Gear for Canon EF 100mm IS USM Macro Lens
$ 65.00
Ikelite Focus Gear for Canon EF 100mm IS USM Macro Lens
Ikelite SKU: 5509.71 | Helix SKU: 550971
Overview
For use with DL port systems. Refer to the appropriate lens port chart for complete compatibility information.
What's Included
- Zoom sleeve
Ikelite GoPro Mount Kit for DSLR Housing
$ 94.95
Ikelite GoPro Mount Kit for DSLR Housing
Ikelite SKU: 2602.5 | Helix SKU: 26025
Overview
Mount your GoPro to any Ikelite DSLR housing featuring a central top mount.Â
What's Included
1" Ball Mount at DSLR Top Mount # 4081.6
1" Ball Clamp for Lightweight Accessories # 4081.21
1" Ball Mount for GoPro # 4081.73
Documentation
Ikelite Locking Stainless Steel Lid Snap
$ 19.95
Ikelite Locking Stainless Steel Lid Snap
Ikelite SKU: 0182 | Helix SKU: 0182
Overview
Replacement stainless steel lid snap with lock as used on Ikelite DSLR, compact digital, and video camcorder housings. Lid hook and mounting hardware not included.
Ikelite Nikon D810 Housing 200DL
$ 1,695.00
Ikelite Nikon D810 Housing 200DL
Ikelite SKU: 71009 | Helix SKU: 71009
Overview
A full featured and durable waterproof housing for Nikon D810Â DSLR cameras. Suitable for scuba, snorkel, surf, pool, and any application in or around the water.
This housing requires the addition of a compatible DL Lens Port for waterproof operation. Lens Port not included.
Features
This popular model has been completely re-designed from the ground up to include all of our latest improvements.
Lens Ports
The single most important upgrade is our long awaited new Dry Lock (DL) port system. This exciting new system is even more robust and even easier to assembly than our time-tested Four Lock (FL) system. The new ports are lighter and more adaptable, and can accommodate extremely large diameter lenses with ease. If you're considering shooting professional quality lenses like the Nikon 14-24mm or Sigma 10-20mm HSM, then the DL system is essential.
Most popular zoom lenses and select lens focus rings can be engaged using a simple yet effective gearing system that puts adjustment right at your fingertips. A large, soft-touch lobed knob on the side of the housing makes fine tuned adjustments a breeze. Zoom and focus gears differ depending on which lens you are using. All are lightweight and affordable. Refer to the DL System Port Chart to choose the correct gear. Zoom gears sold separately.
Due to differences in mount diameter and zoom engagement, DL and FL system ports cannot be used interchangeably. The DL port mount may be removed and replaced with old style Port Locks for FL Port System (Set of 4) # 5509.04 for legacy users with standard or modular ports from our Four Lock system. This modification will prevent the use of newer DL ports. The housing cannot be converted back and forth repeatedly. Re-installation of the DL port base will require the housing to be returned to Ikelite or an Authorized Dealer and may incur additional service charges. There are significant advantages to upgrading your lens ports which you can read about here. If you're shooting an 8" diameter dome, you'll also save almost 2 pounds by using the DL version instead.
Vacuum System
The included vacuum valve allows you to vacuum test the housing to check for leaks prior to putting your expensive equipment in the water. Combined with a full view of the camera and o-ring seal through the back of the housing, there is no greater assurance that your gear will be safe. Our signature open-groove design suspends the rear o-ring in a natural position that is easier to maintain and more reliable than forcing the o-ring into a channel. Use of the vacuum valve requires a compatible Vacuum Pump with Gauge # 47011, sold separately.
TTL Exposure
This housings supports your choice of shooting all manual or adding a TTL converter depending on your application. The flash bulkhead has been moved to the top of the case for improved cord routing and reduced strain. Reliable locking connectors between the hotshoe and bulkhead make it easy to install the optional TTL hotshoe or carry back up parts when traveling to remote locations.
You can still enjoy the fastest and most accurate TTL exposure on the market by adding the NT2 Nikon TTL Hotshoe # 46064, Nikon TTL Converter with Ikelite plug # 4301.3, and a compatible Ikelite DS strobe. Exposure compensation can be used added or subtracted in the camera.
Controls and Set-Up
We've upgraded the shutter and AF-ON levers to a more natural feeling curved design. Both controls can optionally be extended using the Shutter Trigger Extension # 4077.93 for more comfortable use when using a right-hand quick release handle. If you're not already using back button focus, we recommend learning this valuable trick.
Our push buttons have been redesigned to reduce weight and salt build-up. The back of the housing features laser engraved control symbols which will never fade or fall off.
The camera mount is now front-loading for easy installation and removal. A small mounting plate attaches to the bottom of the camera and secures in the front of the housing. The camera mounting plate does not need to be removed from the camera for surface use or when changing the battery or memory cards. The mounting plate features a 1/4-20 threaded mount on the bottom so that it can be attached to a tripod on the surface.
Viewfinders
The included Supereye Viewfinder provides an enhanced view of the camera's optical viewfinder when viewed through a dive mask. The viewfinder removes quickly and easily for the attachment of an optional Straight Magnified Viewfinder # 6890 or 45° Magnified Viewfinder (Type 1) # 6891.1.
Handling & Travel
Overall the housing is over 1/2 pound lighter than its former FL counterpart (housing model # 6812.81). Our new hard anodized aluminum base with quick release handle has also been streamlined for travel and is over 3/4 pound lighter than our previous DSLR tray and handle system. The Right-Hand Quick Release Handle # 4077.02 (sold separately) can be added or removed depending on how you want to shoot. The precision machined aluminum base features 1/4-20 tripod mounting sockets and additional mounting locations for future accessories. Plus, the base and handle can be quickly removed when breaking down your system for travel.
A 1/4-20 threaded mounting point is located front and center on the housing above the lens port mount. This mount can be used to attach lightweight accessories like a focus light or GoPro camera.
If you're shooting with two strobe or lighting arms, then a top handle can be added to make the system easier to carry to and from the dive site. Top handles are available in a Cable Grip # 4080.07 or Aluminum Top Handle # 4080.08. The rigid aluminum version provides additional mounting points for lighting and accessories.
Construction
Our new white ABS-PC blend front is stronger than its clear counterpart, provides improved contrast and visibility, and keeps your camera running cooler in the sun.
Like its predecessor and all of our housings, this product is made in the USA, individually inspected for fit, and water pressure tested to 200 feet (60m).
TTL Exposure
Install optional Nikon TTL Hotshoe Product #Â 46064 and connect the TTL Converter Product #Â 4301.3 for automatic TTL exposure with compatible Ikelite DS-model Strobes. Ikelite DS-model strobes may be used with this system without the TTL Hotshoe and Converter, but will not provide TTL exposure.
Non-Ikelite Strobes
SEA&SEA, INON, and Nikonos strobes with an electrical connection can be triggered in manual exposure modes using an electrical sync cord. Strobes without an electrical sync cord connection cannot be attached to this system unless slaved off of a hard-wired strobe.
Ikelite Non-Digital Strobes
Older non-digital strobes featuring an ICS-5 electrical sync cord bulkhead can be used with this system in manual exposure modes.
Fiber Optic
Fiber optic only strobes are not compatible with this installation. An external strobe must be connected by electrical sync cord.
Remote Triggering
Strobes with remote slave capabilities may be triggered off of a flash attached to the housing by electrical sync cord. Ikelite DS strobes support remote triggering using the Optical Slave Converter Product number 4403 or the Water Wizard system (manufactured and sold by Aquatica).
Compatibility
This housing is only compatible with the Nikon D810Â DSLR as shipped by the manufacturer. Unless otherwise noted, this housing does not accommodate the use of add-on grips, battery grips, eyepieces, LCD covers, or other accessories.
Differences in lens and control placement prevent other DSLR models from being used in this housing. We are not aware of any other models which may be used in or adapted to this particular housing.
Specifications
200' (60m) depth rating
Compatible with DL system lens ports
Controls are provided for all important camera controls; Controls are not provided for Release mode dial, Release mode dial lock release, Diopter adjustment control, Eyepiece shutter lever, Pv button, Fn button, Focus-mode selector, BKT button, Focus selector lock
1/4-20 thread base mounts with 3.5" spacing
Near neutral buoyancy in fresh water
Actual buoyancy varies depending on choice of lens and port
4.9Â lb (2.2 kg)
9.1 x 7 x 6.5" (231 x 178Â x 165Â mm)
In the Box
Housing
Rear o-ring # 0132.61
Front o-ring # 0132.45
Base with Left-Hand Quick Release Handle # 4077.67
Port Hole Cover # 0200.92
Zoom Gear Retainer # 75900
Tool for Zoom Gear Retainer # 0945.06
Waterproof Bulkhead Cap # 9104.5
1/16" Hex Key # 0945.16
1/8" Hex Key # 0945.18
Control + Push Button Tip Assortment # 9249
Silicone Lubricant 2cc Tube # 0184.2
Â
Ikelite O-Ring 0132.59 for DSLR & Mirrorless Housings (Type 1)
$ 17.95
Ikelite O-Ring 0132.59 for DSLR & Mirrorless Housings (Type 1)
Ikelite SKU: 0132.59 | Helix SKU: 013259
Overview
For select DSLR & Mirrorless housing models. Refer to your housing documentation for compatibility. Lubrication is not required but Ikelite silicone lubricant may be used if needed to clean the o-ring.
Ikelite Port Locks for FL Port System (Set of 4)
$ 29.95
Ikelite Port Locks for FL Port System (Set of 4)
Ikelite SKU: 5509.04 | Helix SKU: 550904
Overview
Set of four port locks. Used to convert a housing with the Dry Lock (DL) port system to accept legacy lens ports designed for the Four Lock (FL) port system.
Ikelite Red Filter M27 for Gamma
$ 19.95
Ikelite Red Filter M27 for Gamma
Ikelite SKU: 1871 | Helix SKU: 1871
Overview
Red light maintains your night vision, and helps in observing underwater life without scaring it off. Threads onto the front of the Gamma flashlight and other lights with M27 (27mm) thread. The filter can be removed and replaced underwater. Includes diffuser and lanyard.
Ikelite Smart Charger for DS161, DS160, DS125 NiMH Battery Packs - USA
$ 45.00
Ikelite Smart Charger for DS161, DS160, DS125 NiMH Battery Packs - USA
Ikelite SKU: 0083.92 | Helix SKU: 008392
Overview
Auto-ranging input allows the charger to work in any country whose electrical system falls within a 100V - 240V range. Available with USA, European, UK, or Australian non-interchangeable AC plug. Can be used with a quality travel adapter (not included). This charger is perfect for travel at less than half the size of our previous model smart charger.
For use only with NiMH battery packs for DS161, DS161, and DS125 strobes. Not suitable for use with lithium ion (li-ion) battery packs.
Ikelite ST1K Sony Alpha TTL Kit with Hotshoe
$ 374.95
Ikelite ST1K Sony Alpha TTL Kit with Hotshoe
Ikelite SKU: 46040 | Helix SKU: 46040
Overview
Housing Compatibility
- # 71472 / 200DL Housing for Sony Alpha A7 II, A7R II, A7R II
- # 71473 / 200DL Housing for Sony Alpha A7 III, A7R III, A9
Not compatible with any other models except as listed above
Not compatible with non-Ikelite housings
Strobe Compatibility
- Ikelite DS50 above serial # 70000
- Ikelite DS51
- Ikelite DS125 above serial # 5000
- Ikelite DS160, DS161
- Ikelite DS200 above serial # 7163
Ikelite Strap Wrench to Remove Ports
$ 10.00
Ikelite Strap Wrench to Remove Ports
Ikelite SKU: 0945.01 | Helix SKU: 094501
Overview
Multi-use rubber strap wrench. Perfect for disassembly of the Modular Port System, or removing ports from compact digital housings.
This product is not made by Ikelite. Actual product style and specifications subject to change.
Ikelite Sync Cord Two Ikelite Strobes to Ikelite Bulkhead (Updated)
$ 160.00
Ikelite Sync Cord Two Ikelite Strobes to Ikelite Bulkhead (Updated)
Overview
Y-shaped sync cord with Ikelite-style plugs on all ends. Supports TTL operation with any compatible system featuring an Ikelite-style electrical bulkhead and two DS strobes. The Ikelite-style plug is widely recognized as the most reliable waterproof strobe sync connection available. Built-in strain reliefs reduce stress on cord ends.
This cord is a direct replacement for the prior version # 4103.52. The Ikelite plugs now feature hard anodized aluminum fittings. Overall the cord is significantly lighter while maintaining the same durability as the original nickel plated brass product.
Compatible with all Ikelite housings featuring an electrical bulkhead, Ikelite TTL Converters, and select housings from other manufacturers that have been upgraded with an Ikelite electrical bulkhead.
To connect two strobes to a single housing bulkhead, use a single sync cord # 45151 instead.
In the Box
Sync Cord
(3) Connector Protector Ikelite end # 0301.12
Silicone Lubricant 1cc 1cc tube
Â
Ikelite Type 2 45 degree Magnified Viewfinder
$ 949.95
Ikelite Type 2 45 degree Magnified Viewfinder
Ikelite SKU:Â 6891.2 | Helix SKU:Â 68912
Overview
Ikelite Underwater Housing and Olympus Tough TG-5 Camera Kit
$ 699.00
Ikelite Underwater Housing and Olympus Tough TG-5 Camera Kit
Ikelite SKU: 6233.07 | Helix SKU: 623307
Overview
The TG-5 has a fast 25-100mm mid-range zoom lens with a macro mode that betters almost every other compact out there right now. The TG-5 supports ultra HD 4K video and RAW image capture, which is a powerful tool for post-dive color corrections using either Adobe Lightroom or the included software. The TG-5 is waterproofed to 50' (15.2m) even without a housing, making it the ideal outdoor companion.
This housing is designed for a deeper depth rating and more robust handling than the comparable Olympus brand model. The front of the lens port has a standard 67mm thread for the direct attachment of most popular wide angle and macro wet lenses. A side-mounted shutter lever is more comfortable to use than top mounted styles.
Strobe Compatibility
Due to the position of the camera's flash in relation to its lens, the built-in flash is not suitable to illuminate photos under water. For the best color and clarity, we recommend adding a filter, strobe, or constant-on light. The built-in flash may be used to trigger external strobes via fiber optic sync cord. Two ports are provided for the connection of up to two fiber optic cords.
Any Ikelite DS strobe may be connected using the Fiber Optic Converter # 4401.1 and Fiber Optic Cord # 4501. The AF35 strobe is not compatible with this housing.
Fiber optic cord compatibility
- Ikelite Fiber Optic Coiled Cord # 4501
- INON Optical D Cable "Non-wireless type" L-Connector
- SEA&SEA Fiber Optic Cable (L-type) # 50107
- SEA&SEA Fiber Optic Cable II # 50128
- Olympus UW Fiber Optic Cable PTCB-E02
- Nauticam Optical Fiber Cable # 26211 Nauticam to INON
- Nauticam Optical Fiber Cable # 26212 Nauticam to Sea&Sea
Specifications
- 200 ft (60m) depth rating
- Controls for all camera functions except INFO button
- Slightly positive buoyancy in fresh water
- Central 1/4-20 thread tray mounting
- Weight 1.1 lb (500 g)
- Dimensions 6.2 x 5.5 x 3.6 in (158 x 141 x 85 mm) including projections
- 3.0" diameter glass lens port with 67mm thread
What's Included
- Underwater Housing # 6233.06
- Olympus Stylus TOUGH TG-5 Digital Camera (Red)
- LI-92B Rechargeable Lithium-Ion Battery (3.6V, 1350mAh)
- CB-USB8 Cable (26")
- F-2AC AC Adapter
- Wrist Strap
- Software CD-ROM
- Limited 1-Year Warranty
Ikelite UR/Pro Blue Water External Color Filter for WP80
$ 99.95
Ikelite UR/Pro Blue Water External Color Filter for WP80
Ikelite SKU:Â 644145 | Helix SKU:Â 644145
Overview
Enhances warm reds and oranges with available sunlight up to 80' (24m). Secures to the outside of the Ikelite lens port offering easy installation and removal.
Â
Â
Ikelite Vacuum Kit for 1/2 Inch Accessory Port and DSLR Top Mount
$ 194.95
Ikelite Vacuum Kit for 1/2 Inch Accessory Port and DSLR Top Mount
Ikelite SKU: 47012 | Helix SKU: 47012
Overview
Most newer housings with an opaque white front feature a spare 1/2-20 threaded accessory port. The plug of this spare port may be replaced with this vacuum valve.
Additionally, it can be installed in place of the 1/4-20 top mount featured on all DSLR housings produced since 2009.
Ikelite Vacuum Kit for 3/8 Inch Control Gland
$ 184.95
Ikelite Vacuum Kit for 3/8 Inch Control Gland
Ikelite SKU: 47013 | Helix SKU: 47013
Overview
This valve is appropriate for older clear housings which do not feature a spare accessory port. Simply remove any control with a knob and replace it with this vacuum valve. Refer to the Vacuum System Compatibility Chart (below) for suggestions of where to install the valve.
We do not offer the addition of a spare accessory port.
Ikelite Vacuum Pump Tubing Insert
$ 15.00 - Sold Out
Ikelite Vacuum Pump Tubing Insert
Ikelite SKU: 47005 | Helix SKU: 47005
Overview
Tubing hose fitting for Vacuum Pump with Gauge, Product number 47011. Vacuum pump sold separately.
Ikelite Vacuum Pump with Gauge
$ 59.95
Ikelite Vacuum Pump with Gauge
Ikelite SKU: 47011 | Helix SKU: 47011
Overview
Hand pump with gauge for vacuum valves.
Ikelite Vacuum Valve for 1/2 Inch Accessory Port and DSLR Top Mount
$ 124.95
Ikelite Vacuum Valve for 1/2 Inch Accessory Port and DSLR Top Mount
Ikelite SKU: 47001 | Helix SKU: 47001
Overview
Most newer housings with an opaque white front feature a spare 1/2-20 threaded accessory port. The plug of this spare port may be replaced with this vacuum valve.
Additionally, it can be installed in place of the 1/4-20 top mount featured on all DSLR housings produced since 2009.
Ikelite Vacuum Valve for 3/8 Inch Control Gland
$ 124.95
Ikelite Vacuum Valve for 3/8 Inch Control Gland
Ikelite SKU: 47003 | Helix SKU: 47003
Overview
This valve is appropriate for older clear housings which do not feature a spare accessory port. Simply remove any control with a knob and replace it with this vacuum valve. Refer to the Vacuum System Compatibility Chart (below) for suggestions of where to install.
We do not offer the addition of a spare accessory port.
Ikelite Viewfinder Removal Tool
$ 30.00 - Sold Out
Ikelite Viewfinder Removal Tool
Ikelite SKU: 0945.04 | Helix SKU: 094504
Overview
This tool has been replaced with the Viewfinder Removal Tool V2 # 0945.02, which is compatible with the following accessory viewfinders:
- 45 Degree Magnified Viewfinder for DSLR and Mirrorless Housings (Type 1) # 6891.1
- 45 Degree Magnified Viewfinder for DSLR and Mirrorless Housings (Type 2) # 6891.2
- 45 Degree Magnified Viewfinder for DSLR and Mirrorless Housings (Type 3) #6891.3
- Straight Magnified Viewfinder for DSLR and Mirrorless Housings (Type 1) # 6890
- Straight Magnified Viewfinder for DSLR and Mirrorless Housings (Type 2) # 6890.1
Â
Tool to remove the Super-Eye, Straight, or 45º Magnified Viewfinders. Anodized aluminum.
